AMX MVP-9000i - Irm; Jsb; Jsi

Programming
131
MVP-9000i 9" Modero® ViewPoint® Touch Panel with Intercom
"^" Button Commands (Cont.)
^IRM
Set the IR
channel.
Pulse the given IR channel for onTime in tenths of seconds. Delay offTime in tenths of a
second before the next IR pulse is allowed. ^IRM allows the command itself to specify the
port number. ^IRM is needed because commands programmed on the panel itself can
only be sent to a single port number. (currently this is defined as 1 only).
Note: The port number of the IR will be the port number assigned in TPD4.
Syntax:
"'^IRM-<port>,<channel>,<onTime>,<offTime>'"
Variable:
port = User-defined port on the device (panel).
channel = 1 - 255 (channel to pulse).
onTime = 1/10th of a second.
offTime = 1/10th of a second.
Example:
SEND_COMMAND Panel,"'^IRM-10,5, 20, 10'"
Sets the port 10 IR channel 5 on time to 1 second and off time to 2 seconds.
^JSB
Set bitmap/
picture alignment
using a numeric
keypad layout for
those buttons with
a defined address
range.
The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative
to the upper left corner of the button.
Syntax:
"'^JSB-<vt addr range>,<button states range>,<new text alignment>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
new text alignment = Value of 1- 9 corresponds to the following locations:
Example:
SEND_COMMAND Panel,"'^JSB-500.504&510.515,1&2,1'"
Sets the off/on state picture alignment to upper left corner for those buttons with variable
text ranges of 500-504 & 510-515.
^JSI
Set icon
alignment using a
numeric keypad
layout for those
buttons with a
defined address
range.
The alignment of 0 is followed by ',<left>,<top>'. The left and top coordinates are relative
to the upper left corner of the button.
Syntax:
"'^JSI-<vt addr range>,<button states range>,<new icon alignment>'"
Variable:
variable text address range = 1 - 4000.
button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons
1 = Off state and 2 = On state).
new icon alignment = Value of 1 - 9 corresponds to the following locations:
Example:
SEND_COMMAND Panel,"'^JSI-500.504&510.515,1&2,1'"
Sets the Off/On state icon alignment to upper left corner for those buttons with variable
text range of 500-504 & 510-515.
1
4
789
6
32
5
0
Zero can be used for an absolute position
1
4
789
6
32
5
0
Zero can be used for an absolute position
