Setup Pages
54
MVP-9000i 9" Modero® ViewPoint® Touch Panel with Intercom
Panel Information Page
The Panel Information page includes four tabs: Info (page 54), Config (page 55), File (page 56), and Project (page 57).
Panel Information Page - Info
The Info tab of the Panel Information page provides detailed panel information (FIG. 62).
Features on this page include:
FIG. 62 Panel Information page - Info
Panel Information Page - Info
Back: Saves all changes and returns to the previous page.
WiFi/Wired icon: The icon to the left of the Connection Status Icon displays whether the current
connection to the Master is Wireless (image of a radio antenna) or Wired
(image of three networked computers).
Connection Status icon: The icon in the upper-right corner of each Setup page provides a constant
visual indication of current connection status.
Note: a Lock appears on the icon if the panel is connected to a secured NetLinx
Master.
Panel Type: Displays the model of the panel being used.
Firmware Version: Displays the version number of the G4 firmware loaded on the panel.
Serial Number: Displays the specific serial number value assigned to the panel.
Setup Pages: Displays the type and version of the Setup pages being used by the panel.
Panel Start Time: Displays the time taken by the panel to wake up from sleep mode.
Screen Width: Displays the screen width (in pixels). MVP-9000i = 800 pixels.
Screen Height: Displays the screen height (in pixels). MVP-9000i = 480 pixels.
File System: Displays the amount of Compact Flash memory available on the panel.
RAM: Displays the available RAM (or Extended Memory module) on the panel.
Bulb Hours: Displays the number of hours elapsed with the display.
