Programming
154
MVP-9000i 9" Modero® ViewPoint® Touch Panel with Intercom
^RAF, ^RMF - Embedded Codes
The ^RAF and ^RMF commands add and modify any and all resource parameters by sending embedded codes and data:
"'^RAF-<resource name>,<data>'"
"'^RMF-<resource name>,<data>'"
The <data> variable uses the embedded codes described in the following table:
Dynamic Image Commands (Cont.)
^RMF
Modify an
existing resource.
Modifies any and all resource parameters by sending embedded codes and data.
Since the embedded codes are preceded by a '%' character, any '%' character contained
in the URL must be escaped with a second '%' character (see example).
The file name field (indicated by a
%F embedded code) may contain special escape
sequences as shown in the
^RAF, ^RMF - Embedded Codes section on page 154.
Syntax:
"'^RMF-<resource name>,<data>'"
Variables:
• resource name = 1 - 50 ASCII characters
• data = Refers to the embedded codes, see the
^RAF, ^RMF - Embedded Codes section
on page 154.
Example:
SEND_COMMAND Panel,"'^RMF-Sports_Image,%ALab%%5FTest/
Images%Ftest.jpg'"
Changes the resource ’Sports_Image’ file name to ’test.jpg’ and the path to ’Lab_Test/
Images’.
Note that the
%%5F in the file path is actually encoded as %5F.
^RSR
Change the
refresh rate for a
given resource.
Syntax:
"'^RSR-<resource name>,<refresh rate>'"
Variable:
resource name = 1 - 50 ASCII characters.
refresh rate = Measured in seconds.
Example:
SEND_COMMAND Panel,"'^RSR-Sports_Image,5'"
Sets the refresh rate to 5 seconds for the given resource (’Sports_Image’).
^RAF, ^RMF - Embedded Codes
Parameter Embedded Code Description
protocol
’%P <0-1>’
Set protocol. HTTP (0) or FTP (1).
user
’%U <user>’
Set Username for authentication.
password
’%S <password>’
Set Password for authentication.
host
’%H <host>’
Set Host Name (fully qualified DNS or IP Address).
file
’%F <file>’
Full path to the location of the file or program that will return
the resource. The path must be a valid HTTP URL minus the
protocol and host.
The only exception to this is the inclusion of special escape
sequences and in the case of FTP protocol, regular
expressions.
path
’%A <path>’
Set Directory path. The path must be a valid HTTP URL minus
the protocol, host and filename.
The only exception to this is the inclusion of special escape
sequences and in the case of FTP protocol, regular
expressions.
refresh
’%R <refresh 1-65535>’
The number of seconds between refreshes in which the
resource is downloaded again. Refreshing a resource causes
the button displaying that resource to refresh also.
The default value is 0 (only download the resource once).
