Accessories
15
MVP-9000i 9" Modero® ViewPoint® Touch Panel with Intercom
The MVP-9000i touch panel remains locked in the MVP-WDS-9 until unlocked by the user. This may be done by
entering an appropriate password (please refer to the Passwords section on page 84 for more information), or by pressing
the Security Release button on the front of the device in emergencies. The station ejects the device top first. The device
uses two neodymium rare-earth magnets to keep the MVP-9000i from falling out of its cradle when the touch panel is
angled forward.
Unlocking the Touch Panel
For information on removing a touch panel locked into the MVP-WDS-9, please refer to the Undocking from the MVP-
TDS-9 or MVP-WDS-9 on page 22.
MVP-WDS-9 Specifications (Cont.)
Operating/Storage
Environments:
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Battery Charging Temperature: 0° C (32° F) to 30° C (86° F)
• Operating & Battery Charging Humidity: 20% to 85% RH
• Storage Temperature: -10° C (-14° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories • MVP-WDS-9 Wall Docking Station Installation Guide (93-5967-12)
• Snap-On Ferrite (04-0007)
• MVP-WDS-9 Wall Docking Station Template (68-5967-01)
• PS-POE-AT High Power PoE Injector (FG423-81)
Other AMX
Equipment:
• MVP-9000i-GB Modero Wireless Touch Panel, Black (FG5967-01)
• MVP-9000i-GW Modero Wireless Touch Panel, White (FG5967-02)
• MVP-TDS-9-GB Black Table Docking Station (FG5967-10)
• MVP-TDS-9-GW White Table Docking Station (FG5967-11)
• CB-MVP-WDS9 Rough-In Box (FG038-13)
FIG. 11
MVP-WDS-9-GB Wall Docking Station - Side view
MVP-9000i
Wall Docking Station
Security Release button
