Andor Technology iXon3 Series User Manual

Page 44
iXon 3
Since all X3 cameras have iCam technology, the rising edge of the external trigger can occur before the end of the
previous read out provided that the falling edge of the Fire pulse occurs after the readout has completed, i.e. the external
triggerisonlyaccepteduptothe“userdeneddelayperiod”beforetheendofthereadout.Thisenhancedtriggermode
will result in a higher frame rate (see gure 30 below):
Features & Functionality
Figure 30: ‘iCam-enhanced’ External Trigger in Frame Transfer mode
