36
Parameter Settings – F 20 (Continued)
Refer to the previous table for the encoder resolution settings for common ANILAM
encoders.
NOTE: If the table does not list the encoder resolution setting for the encoder you are
using and you do not know the exact encoder resolution, call ANILAM for
advice. If you are using BT or JB linear encoders (inch linear encoders) refer
to the Inch Linear Encoders
section.
If you need to change the encoder resolution setting:
4. Enter the setting for the encoder you are using listed in the table.
To change the direction of travel:
5. Press
+
_
to change the direction of
positive travel.
6. Press
to set the encoder
resolution and direction of
travel.
