Parameter Settings – F 20 (Continued)
This setting is for the resolution of the axis display(s) when you have toggled the
MM/INCH key to INCH mode only. The axis designation is blinking indicating that you
can enter a value. The DRO will default the same display resolution as the encoder
resolution (in this example, .0002 INCH). ANILAM recommends that you use the same
display resolution as the encoder resolution.
9. Press
+
_
to scroll through the display
resolution options.
The display resolution options for INCH mode are:
.00001, .00002, .00005 .0001, .0002, 0005, .001, .002, .005, .01, .02, Inches
NOTE: If the selected display resolution is coarser than the encoder resolution, the
DRO turns on the Coarse Resolution Symbol in the axis display(s).
10. Press
to select the desired display
resolution in INCH mode.
The DRO displays one of the following in the axis display:
Option Setting Linear Encoder
i20 r05 RBS-.5T and RBM-.5T
i20 r1 RBS-1T and RBM-1T
i20 r5 RBS-5T and RBM-5T
no E-trac All other linear encoders
To Next Page
