14
Figure: Mount the first battery module and floor mounting base.
a
c
d
e
＜5 mm/0.5
︒
BMS
BAT-
BAT+
BMS
BAT-
BAT+
2N·m
M5×14 mm
BMS BAT- BAT+
BMS BAT- BAT+
BMS BAT- BAT+
BMS BAT- BAT+
b
Mount the remaining modules from bottom to top. After installing a module, tighten the module interlockers using the
included screws (M5×14 mm), and then mount the next module.
Figure: Mount the second and third battery modules.
b
c
2N·m
M5×14 mm
a
BMS
BAT-
BAT+
BMS
BAT-
BAT+
