22
Figure: Mount the power module.
a
BAT-
BAT+
b
c
2N·m
M5×14 mm
If necessary, insert the included wedge shim into the power module's mount bracket to ensure stability.
Figure: Insert the wedge shim.
When adding the second column, attach the top cover to the top battery module using the screws (M5×14 mm, included).
