Anritsu ML2400A Series User Manual

1-6 SENSORS The fol low ing sen sors, sen sor op tions, and sen sor ac ces so ries are avail -
able for use with the ML2400A Se ries Power Me ters:
Power Sen sors (–70 to + 20 dBm)
Model No.
Range
MA2469A 10 MHz – 14 GHz
(–60 to +20 dBm, nominal bw 1.2 MHz)
MA2472A 10 MHz – 18 GHz
MA2473A 10 MHz – 32 GHz
MA2474A 10 MHz – 40 GHz
MA2475A 10 MHz – 50 GHz
Ther mal Sen sors (–30 to + 20 dBm)
Model No.
Range
MA2421A 100 KHz to 18 GHz
MA2422A/B 10 MHz – 18 GHz
MA2423A/B 10 MHz – 32 GHz
MA2424A/B 10 MHz – 40 GHz
MA2425A/B 10 MHz – 50 GHz
High Ac cu racy Sen sors (–64 to +20 dBm)
Model No.
Range
MA2442A 10 MHz – 18 GHz
MA2444A 10 MHz – 40 GHz
MA2445A 10 MHz – 50 GHz
Sen sor Op tions
MA2400A- 10 Ex tra Cal Fac tor Freq., 0.01 – 40 GHz
Sen sor Ac ces so ries
ML2400A- 20 1.5m Sen sor Ca ble
ML2400A- 21 0.3m Sen sor Ca ble
ML2400A- 22 3m Sen sor Ca ble
ML2400A- 23 5m Sen sor Ca ble
ML2400A- 24 10m Sen sor Ca ble
ML2400A- 25 30m Sen sor Ca ble
ML2400A- 26 50m Sen sor Ca ble
ML2400A- 27 100m Sen sor Ca ble
ML2400A-29 Bulk head Adapter
MA2499B An ritsu Sen sor Adapter
MA2497A HP Sen sor Adapter
1N75C 5W Lim iter, 0.01 – 3 GHz , Nm-f , 75W
1N50C 5W Lim iter, 0.01 – 18 GHz , Nm-f , 50W
1K50A 5W Lim iter, 0.01 – 20 GHz , Km-f, 50W
1K50B 3W Lim iter, 0.01 – 26 GHz , Km-f, 50W
42N75- 20 5 Watt Attenua tor , Nm-f , 75
Ω
42N50-20 5 Watt Attenua tor , Nm-f , 50 Ω
42N50- 30 50 Watt Attenua tor , Nm-f , 50 Ω
42KC- 20 5 Watt Attenua tor , Km-f, 50 Ω
ML2400A OM 1-3/1-4
GENERAL SENSORS
INFORMATION
NOTE
The use of sen sor ca -
bles greater than 10
me ters in length is not
rec om mended when
mea sur ing pulses of
less than 10
ms.
