6-5 GPIB PC CARD
SETUP
The fol low ing GPIB driver con fig u ra tion set up is rec om mended for re li able
GPIB com mu ni ca tion with the ML2400A Se ries power me ter. The set up is ex -
pressed in the terms used by the Na tional In stru ments GPIB ISA and PCI
cards and driv ers for WIN95 and DOS.
GPIB De vice Tem -
plate
The ML2400A Se ries de fault pri mary ad dress is 13. Sep a rate de vice tem plates
for the pri mary ad dress of each de vice can usu ally be set up sep a rately. The
set tings for the de vice tem plate for the ML2400A Se ries are:
Ter mi nate read on EOS NO
Set EOI with EOS on write YES
Type of com pare on EOS 8 bit
EOS byte 0x0A (10 dec i mal)
Send EOI at end of write YES
Re ad dressing YES
Sec ond ary ad dress NONE
GPIB Card Set tings The rec om mended GPIB card set tings for use with the ML2400A Se ries are:
Ter mi nate read on EOS NO
Set EOI with EOS on writes YES
Type of com pare on EOS 8 bit
EOS byte 0x0A (10 dec i mal)
Send EOI at end of write YES
Sys tem con trol ler YES
As sert REN when SC YES
En able Auto Se rial poll ing NO
NI card. Ca ble length for HS488 OFF
ML2400A OM 6-5
GPIB OPERATION GPIB PC CARD SETUP
