Anritsu ML2400A Series - 4-7 SYSTEM MENU

4-7 SYSTEM MENU The Sys tem menus con trol the op er at ing modes, dis play vis i bil ity, sound, rear
panel func tions, and bat tery state of the ML2400A Se ries Power Me ter. Note
that the soft keys will ap pear dif fer ently de pend ing upon the op er a tion mode
se lected with the Setup soft key be low.
NOTE
When ed it ing an en try in a menu, press ing the
CLR key
clears the dig its. If in a menu screen, press ing the
CLR
key re turns to the pre vi ous menu level.
Setup This menu se lects the op era tion mode, al lows sys tem set ups to be saved or re -
called, and pro vides two op tions to re set the sys tem pa rame ters to the de fault
setup.
MODE
[OPMD]
Se lect be tween Read out, Power vs. Time, Source Sweep and Pro -
file op er a tion modes. If only Read out mode is avail able, check the
Sys tem|Rear Panel|GPIB|Mode set ting. This set ting must be
ML24XX for Pro file, Power vs. Time, and Source Sweep modes to
be avail able.
Read out mode can be ei ther STANDARD or CDMA. CDMA Read -
out mode re moves Pro file and Source Sweep modes, leav ing only
Read out and Power vs. Time modes. CDMA mode al lows
AVERAGE, CREST and PEAK mea sure ments to be made on
IS95 type sig nals.
When CDMA mode is se lected, a
CDMA mode activ e mes sage will
be dis played on the top line of the dis play.
SAVE
[*SAV
SYSLD
SYSRD
SYSLNM]
Save the cur rent in stru ment setup in one of 10 mem ory lo ca -
tions. The read out mode set ting (STANDARD or CDMA) is also
saved.
RE CALL
[*RCL
SYSLD
SYSRD
SYSLNM]
Re call a saved in stru ment setup from one of 10 mem ory lo ca -
tions. When re call ing a setup that in volves the read out mode
chang ing be tween STANDARD and CDMA, the in stru ment will
re boot to the stored mode.
LINK
[LINK]
There are two trig ger con di tions saved; one for Pro file mode and
one for Read out mode. Nor mally, Pro file mode trig ger con di tions
can be changed with out af fect ing the trig ger con di tions used in
Read out mode. With LINK set to ON, the Pro file mode trig ger
con di tions are used for both Pro file and Read out modes.
In Pro file mode, the user can view what is be ing meas ured with
the se lected trig ger con di tions, but only over a lim ited dy namic
range, as it only uses the two DC ranges of the sig nal chan nel.
Pro file mode mea sure ment rate is also lim ited by sweep speed.
ML2400A OM 4-21
OPERATION SYSTEM MENU
NOTE
When us ing the
ML2400A Se ries
Power Me ter with an
MA2499A or MA2499B
Sen sor Adapter, only
Read out and Power vs.
Time modes are al -
lowed.
