Chap ter 3
Con nec tions
3-1 INTRODUCTION This chap ter de scribes physi cal con nec tions to the power me ter on both
the front and rear pan els.
3-2 FRONT PANEL
CONNECTORS
The front panel con nec tors are il lus trated in Fig ure 3-1. De tailed de -
scrip tions of each con nec tor fol low.
Cali bra tor
0.0 dBm Ref er ence
This con nec tor is a pre ci sion fe male N- Type, 50 Ohm con nec tor that pro vides a
pre ci sion, trace able 0.0 dBm, 50 MHz ref er ence sig nal for ab so lute cali bra tion
of the sen sors. The cali bra tion sig nal can be turned on or off through the
Cal/Zero menus (see Chap ter 4, Front Panel Op era tion). Use only com pati ble
50 Ohm N- Type con nec tors.
ML2400A OM 3-1
Figure 3-1. Model ML2400A Se ries Power Me ter Front Panel Con nec tors
Calibrator
Connector
Sensor A
Connector
Sensor B
Connector
(ML2408A only)
