Anritsu ML2400A Series - Rack Mounting

ML2400A-01 Rack
Mount Installation
This section describes the assembly procedure for fitting a single ML2400A
Power Meter (PM) unit into an instrument rack. The PM must be fitted with
rack mount top and bottom covers before the rack mount kit can be fitted.
The procedure involves fitting the support bracket to the PM. The PM can
then be loaded and secured in the rack position desired.
The required parts and tools are listed below:
Tools Required: Small Phillips screw driver
Large Phillips screw driver
Small Phillips torque screw driver 10cNm to 120cNm
Assembly drawing “ML2400A/01 RACK MOUNTED
LEFT OR RIGHT OPTION”
Assembly Procedure 1. Confirm the correct tools are available and the parts listed above are present.
Refer to diagram on page 2-5 throughout this procedure.
2. Fit the two handles 783-1055 to front plate 49362 and the front rack bracket
C37376 using 4 screws 900-795.
2-4 ML2400A OM
RACK MOUNTING INSTALLATION
Quantity
(each)
Description
Anritsu Part
Number
Max. Torque
Setting
2
HANDLE, PULL, CHASSIS, PLASTIC, HARDWARE
783-1055
4
SPEED NUT
790-319
8
6-32, SST, WASHER, FLAT
900-345
4
M4, 8.00 MM, PHH, SCREW, FLAT HEAD
900-795
4
DECORATIVE SCREW
900-821
8
M3X8, POS, SST, PATCHLOCK, SCREW, METRIC,
PAN HEAD
905-68 .4lbf.in
[45cN m]
6
M3X5, POS, SST, PATCHLOCK, SCREW, METRIC,
PAN HEAD
905-72 .4lbf.in
[45cN m]
6
SNAP RIVET, PLASTIC
788-575
1
RACK MOUNT, SIDE, BRACKET
C37276
1
REAR SUPPORT, BRACKET, RACK MOUNT
C41449
1
RACK MOUNT, SUPPORT, BRACKET
D41473
1
BRACKET SUPPORT, BASE PANEL
49361
1
FRONT FACE PLATE
49362
1
POWER METER FITTED WITH RACK MOUNT TOP
AND BOTTOM COVERS
ML2400A
Table 2-1 ML2400A-01 Rack Mount Kit Parts List
