With LINK read out/pro file trig ger set to ON, switch ing to Read out
mode uses the same trig ger con di tions, but al lows the full dy -
namic range of the me ter to be used, as well as providing full
GPIB speed on data ac qui si tion.
When moving between Readout and Profile modes, with LINK
en abled, the value used for “sample delay” is modified using the
“display trigger de lay.” In Readout mode, the “sample delay” and
“display trigger delay” values are combined as “sample de lay,”
whereas in Profile mode they are both available separately.
FAST Fast re call of a saved in stru ment setup from one of the 10 mem -
ory lo ca tions. In FAST sys tem re call mode, a sin gle key press re -
calls a saved setup. A message across the lower area of the screen
will prompt for keypad keys 1-9, or 0, to be pressed to re call
setups 1-10 (if saved setup data is available in the se lected lo ca -
tion). The
-exit- soft key or any other menu key will exit fast recall
mode.
PRE SET Re sets the sys tem pa rame ters to the de fault setup (see Ap pen dix
A, Sec tion A-3 ).
RE SET [*RST]
This se lec tion will re set the sys tem setup. The off set ta bles and
the GPIB in ter face will not be af fected. The read out mode will be
set to STANDARD. If the me ter is in CDMA mode, the sys tem
will re boot to STANDARD mode.
FAC TORY [FRST]
This se lec tion will re set the sys tem setup, in clud ing the off set ta -
bles and GPIB in ter face. The read out mode will be set to
STANDARD.
Read out This softkey be comes avail able when the
Sys tem/Setup/MODE is set to
READOUT . Read out op er a tion mode in cludes the fol low ing dis play con trols:
MODE
[RDMODE]
Al lows the in stru ment read out mode to be changed be tween stan -
dard and CDMA (IS95). In CDMA read out, only Read out and
Power vs. Time are al lowed.
HOLD
[PCRH]
Change the PEAK/CREST hold re set status be tween timed re set
and man ual re set.
TIME
[PCRT]
When HOLD is set to TIME, this al lows the re set pe riod to be set
be tween 1 to 30 sec onds.
RE SET
[PCRST]
This will re set the peak and crest for both dis play chan nels. The
front panel CLR key can also be used to re set the peak and crest.
4-22 ML2400A OM
SYSTEM MENU OPERATION
NOTE
When re call ing a setup
in volves the read out
mode chang ing be -
tween STAN DARD and
CDMA, the in stru ment
will re boot.
NOTE
With LINK set to ON,
Read out mode is tem -
po rarily forced to Cus -
tom mode, and the de -
fault and Mod Av er age
modes are inhibited. To
use these modes, de -
se lect LINK.
