val:
Re marks: Sets the high limit. The HLIMS com mand turns the lim its on and off. It
is not nec es sary to en ter the units as the limit value is checked against
the dis played value. There fore, if the lim its have been set for –10 dBm
(HLIM 1, –10) and the dis play units are sub se quently changed from
dBm to Watts, the sys tem will still check for the read ing to rise above
–10, even though the dis play units type has been changed.
Ex am ple: The high limit is set to –10dBm and turned ON. The dis play is in dBm.
A read ing of –9.500dBm would pass. If the dis play is sub se quently
changed to Watts, a read ing of 112.2
mW would fail, be cause the DIS -
PLAYED value is higher than –10. Limit check ing only uses the dis -
played value and does not change its value even though the dis play units
have changed.
Re lated
Com mands: HLIMS
Query: HLIM? <c>
Re turned
String: HLIM <c>,<val>
HLIMS Turn on/off High lim its
CHAN NEL
Syn tax: HLIMS <c>,<state>
c: 1 or 2
state: ON or OFF
Re marks: The HLIMS com mand turns the lim its on and off.
Re lated
Com mands:
HLIM
Query: HLIMS? <c>
Re turned
String: HLIMS <c>,<state>
ML2400A OM 6-51
GPIB OPERATION ML24XXA NATIVE COMMANDS
Units Min Max
dBm –99.99 +99.99
dBmV –53.00 147.00
dB
mV 7.00 207.00
Watts 0.0 50.0
