MXGD Out put Max Graph Data DATA OUT PUT
Syn tax: MXGD
Re marks: Avail able in graph modes only. Out puts in ASCII form the max graph
data.
The for mat is as fol lows:
MX
GD <num ber_of_el e ments>,<el e ment_1>,<el e ment_2>,<el e -
ment_n>...<\n>
The first num ber in the string is the num ber of el e ments to fol low, and
is al ways 200 for the ML2400A Se ries.
O Re turn dis play chan nel read ing
DATA OUT PUT
Syn tax: O <c>
c: 1 or 2
Re marks: Read out and Power vs. Time modes only. R eturns the next measured
reading avail able in the output buffer from the selected chan nel. The
read ing will sit in the out put buffer un til it is read. If an other read ing is
re quested, that read ing will be buff ered af ter the pre vi ous read ing. If the
first read ing re quested is read be fore an other re quest for data, the out -
put buffer will be empty. The MAV bit in the status byte will al ways in -
di cate the state of the buffer. The display is updated at a constant rate
with available readings if the display is on.
If the selected chan nel is turned off, an exe cu tion er ror is re turned. The
re turned string is the value plus a line feed (hex 0X0A), no ter mi na tors.
OBACM AC mod out put po lar ity con figuration
BNC
Syn tax: OBACM <po lar ity>
po lar ity: POS (posi tive)
NEG (nega tive)
Re marks: Changes the po lar ity of the AC mod BNC out put sig nal.
Query: OBACM?
Re turned
String: OBACM <polarity>
OBCH BNC out put port chan nel con figu ra tion
BNC
6-58 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
