OI Output de vice iden ti fi ca tion GPIB 488.2
Syn tax: OI
Re marks: Re turned for mat:
<Com pany name>,<model>,<se rial>,<firm ware ver sion>
ON Out put number of chan nel read ings
DATA OUT PUT
Syn tax: ON <c>,<val>
c: 1 or 2
val: 1 to 1000
Re marks: Read out and Power vs. Time modes only. This com mand re turns the
spec i fied num ber of read ings for the spec i fied chan nel. The read ings are
first as sem bled, and then passed to the GPIB as a whole, with a line feed
char ac ter (hex 0x0a) mark ing the end of the string.
Ex am ple: ON 1, 9
This ex am ple will re turn:
–10.234, –10.234, –10.235, –10.238, -10.250, –10.270, –10.500, –10.934,
–12.234<0x0a>
OPMD ML2400A Se ries op era tion mode
SYS TEM
Syn tax: OPMD <mode>
mode: DIGIT
PRO FILE
PWRTIM
SRCSWP
Re marks: This com mand se lects the ML2400A Se ries op er a tion mode (data col lec -
tion method).
DIGIT = dig i tal read out of chan nel data
PRO FILE = pro file of graphic dis play
PWRTIM = graph of chan nel power ver sus time
SRCSWP = source sweep graphic dis play
To use Graph out put com mands, the ML2400A Se ries must be in Pro file
or Power vs. Time mode. To use the out put chan nel data com mands, the
ML2400A Se ries must be in the dig i tal read out mode.
If the sys tem is in CDMA read out mode and the com mand to set the sys -
tem to Pro file or Source Sweep mode is re ceived, a GPIB ex e cu tion er ror
will oc cur
6-66 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
