SRCSTPWR Source Sweep Start Power SYSTEM
Syn tax: SRCSTPWR <power_value>
power
value: –120 to +30 dB
Re marks: De ter mines the start power level of power sweep mode.
Query: SRCSTPWR?
Re turned
String: SRCSTPWR <power>
START Ini tial startup self test com mand
GPIB SETUP
Syn tax: START
Re marks: This is use ful for ATE con trol. Af ter the sys tem has been given time to
start up, this com mand can be used to find out what state the sys tem is
in. If the self test has failed, 'CONT' can be used to get the sys tem run -
ning. This is an ini tial startup self test status com mand and will re turn
one of the fol low ing:
0 - Passed self test and run ning.
1 - Startup self test run ning.
–1 - Start up self test FAILED.
In this stage of the startup pro cess, all com mands ex cept STERR,
START, CONT and GPIB 488.2 event and status com mands will pro duce
a GPIB exe cu tion er ror. STERR will re turn the selftest re sult string.
Re lated
Com mands: STERR, CONT
STATUS Status Mes sage
DATA OUT PUT
Syn tax: STATUS
Re marks: Re plies with the power me ter’s cur rent state code. In this for mat, the
num ber of let ters spec i fies the num ber of dig its, with pre ced ing ze roes
for pad ding. The for mat is:
’ABCDEFGHIJKLMNNOOPQRRRRSSSSTUVWXYZ12’
where: A = Op er ating mode: '0' = Dig i tal read out, '1' = Pro file mode
chan nel 1, '2' = Pro file mode chan nel 2, '3' = Power vs. Time chan nel 1,
'4' = Power vs. Time chan nel 2.
B = Chan nel 1 in put con fig u ra tion: '0' = OFF, '1' = A, '2' = B, '3' = A–B,
