APPENDIX A SYSTEM DEFAULTS
ML2400A OM A-7
off set type = ta ble
ta ble number 1
fre quen cies 0 Hz
off set val ues 0 dB
SEN SOR - duty cy cle
duty cy cle state off
duty cy cle 100%
CHAN NEL - setup
in put con fig chan 1 = A, chan 2 = off
in put con fig ( HP 437B & HP 438A ) chan 1 = A, chan 2 = off
meas units dBm
meas units ( HP 437B ) dBm
meas units ( HP 438A ) watts
dis play reso lu tion 2 deci mal places
track ing min/max dis play off
CDMA mea sure ments AVERAGE
CHAN NEL - rela tive off
CHAN NEL - lim its
high limit 0 dBm
high limit ( HP 437B ) 90 dBm
high limit ( HP 438A ) 0 dBm
low limit 0 dBm
low limit ( HP 437B ) –90 dBm
low limit ( HP 438A ) 0 dBm
high limit en abled off
low limit en abled off
fail in di ca tor hold off
fail beep con trol off
TRIG GER
SYS TEM - setup = read out or power vs. time
SEN SOR - meas mode = de fault std trig ger mode
SEN SOR - meas mode = mod av er age std trig ger mode
SEN SOR - meas mode = cus tom
TRIG GER - setup
source con tinu ous
sam ple de lay 1 ms
sam ple gate width 20 ms
source = con tinu ous, man ual
trig ger arm ing blank ing off
source = in ter nal A, in ter nal B
trig ger arm ing blank ing off
trig ger type rise
trig ger level > –15 dBm
