APPENDIX A SYSTEM DEFAULTS
ML2400A OM A-9
mode = pro file, power vs time, source sweep
SYS TEM - con trol
scale top dB value 20 dB
scale bot tom dB value –50 dB
read out on
link cur sor off
hold off
SYS TEM - display
bat tery back light on
dis play con trast 5
peak me ter dis play off
frequency/offset display off
GPIB user text display off
back light = timed
time 5 minutes
SYS TEM - sound
key click state off
edit er ror beep off
lim its fail beep chan nel 1 off
lim its fail beep chan nel 2 off
cur sor off screen beep off
SYS TEM - bat tery (if pres ent)
auto power off enable
auto power off time 30 min
SYS TEM - rear panel - GPIB
GPIB ad dress 13 (fac tory pre set only)
emu la tion mode ML24xx (fac tory pre set only)
SYS TEM - rear panel - RS232
mode EXT COMMS
baud rate 9600 (fac tory pre set only)
mo dem re dial count 5
de lay 5 min utes
auto lim its false
range false
power false
SYS TEM - rear panel - BNC
output 1 & 2
mode off
mode = ana log out
chan nel 1
start volts 0 volts
stop volts 5 volts
start dis play value –10 dB
stop dis play value 0 dB
