[PCRST] Peak/Crest RE SET } if Chan nel|Setup|Read out mode=CDMA
Pro file } if sys tem setup mode = Pro file
[GRMD ] CHAN NEL
1 | 2
[GRPRD ] Data col lec tion PE RIOD
100ns to 7 sec onds
[DTRGD ] Dis play trig ger DE LAY
0 to 7 sec onds
[GRPIX ] DATA HOLD rep re sen ta tion
Nor mal | min&max | min | max
PwrVsTime } if sys tem setup mode = Power vs. Time
[GRMD ] CHAN NEL
1 | 2
[GRPIX ] DATA HOLD rep re sen ta tion
Nor mal | av er age | min&max | min | max
[GRDDT ] Data dis play TIME
1 min to 24 hours
Source Sweep } if sys tem setup mode = Source Sweep
[GRMD ] CHAN NEL
1 | 2
[GRPIX ] DATA HOLD rep re sen ta tion
Nor mal | min&max | min | max
[SRCMOD ] Source sweep MODE
Fre quency | power
[SRCSTFRQ, ] Sweep START fre quency or power
[SRCSTPWR ]
10 kHz to 122 GHz
-120.00 dB to +30.00 dB
[SRCSPFRQ, ] Sweep STOP fre quency or power
[SRCSPPWR ]
10 kHz to 122 GHz
-120.00 dB to +30.00 dB
Con trol } if sys tem setup mode = Pro file, Power vs.
} Time or Source Sweep
ML2400A OM C-11
APPENDIX C SYSTEM MENU
