SETUP
[CVSTF
CVSPF
CVSTV
CVSPV]
Sets up the Start and Stop fre quen cies and volt ages when Source
is set to V/GHz. This tells the ML2400A how to de ter mine the
fre quency of the swept sig nal based on the ap plied rear panel
volt age.
Av er aging Sen sor data av er ag ing. The avail able soft keys de pend upon the op er at ing
mode se lected.
In Read out and Power vs. Time modes, the fol low ing soft keys ap pear:
SEN SOR Model ML2408A (dual chan nel) only. Se lect sen sor A or B, in
Power vs. Time or Read out modes.
MODE
[AVG
AVGM]
Se lect OFF, AUTO, MOVING or REPEAT, in Power vs. Time or
Read out modes.
AUTOMATIC av er ag ing uses a MOVING type of av er age and in -
creases the amount of av er ag ing as the noise level increases. The
dis play up dates at ap proxi mately 100 ms in ter vals, how ever the
data is avail able at the full rate. The dis play is slowed down to
pre vent jit ter and al low the user to fol low the up date.
MOVING av er age al lows the user to manu ally se lect the amount
of av er ag ing re gard less of the sig nal level. The dis play is con tinu -
ally up dated while av er ag ing. When se lected, the NUMBER soft
key be comes avail able.
ML2400A OM 4-9
OPERATION SENSOR MENU
NOTE
Au to matic av er ag ing
also ap plies an al go -
rithm to en hance set -
tling at low power lev els
(e.g., sig nal sources).
NOTE
When in CDMA read -
out mode, av er ag ing is
al ways ON, with a min i -
mum value of 16 .
