Data hold = MIN (or MAX) :
1 cur sor 1 min i mum read ing, or max i mum if MAX mode
2 cur sor 2 min i mum read ing, or max i mum if MAX mode
D P Power diff be tween cur sor 1 and cur sor 2 min i mums
(or max i mums if MAX mode)
T1 Time at cur sor 1
T2 Time at cur sor 2
Data hold = MIN&MAX:
1 cur sor 1 MIN read ing
cur sor 1 MAX read ing
2 cur sor 2 MIN read ing
cur sor 2 MAX read ing
D t Time dif fer ence be tween cur sor 1 and cur sor 2
Source Sweep mode
Data hold = NOR MAL or AV ER AGE:
1 cur sor 1 read ing
2 cur sor 2 read ing
D P Power dif fer ence be tween cur sor 1 and cur sor 2
X1 X axis at cur sor 1
X2 X axis at cur sor 2
Data hold = MIN (or MAX) :
1 cur sor 1 min i mum read ing, or max i mum if MAX mode
2 cur sor 2 min i mum read ing, or max i mum if MAX mode
D P Power diff be tween cur sor 1 and cur sor 2 min i mums
(or max i mums if MAX mode)
X1 X axis at cur sor 1
X2 X axis at cur sor 2
Data hold = MIN&MAX:
1 cur sor 1 MIN read ing
cur sor 1 MAX read ing
2 cur sor 2 MIN read ing
cur sor 2 MAX read ing
