com mands (DTRGD and GRPRD) in this group do not change how the sys tem
trig gers, only where the graph is drawn af ter a trig ger has oc curred. Re fer to
the TRIGGER group func tions to con fig ure the mea sure ment trig ger ing.
SEN SOR The SENSOR group com mands se lect the data ac qui si tion con trols for the se -
lected sen sor.
SYS TEM The SYSTEM group com mands con trol the over all func tion al ity of the
ML2400A Se ries Power Me ter, in clud ing the sys tem op er a tion mode, cur sor
con trol, dis play con fig u ra tion, sound, print ing, bat tery con trol and sta tus, rear
panel con fig u ra tion, graph ics, sys tem se cu rity, and sys tem iden tity.
TRIGGER The TRIGGER group func tions are used to pro gram the trig ger ing of mea sure -
ment data. TRIGGER group com mands are avail able in PROFILE op er a tion
mode, and in READOUT mode if the
SENSOR|SETUP|MODE submenu is set
to CUSTOM.
In CUSTOM, the chan nels are trig gered si mul ta neously if the trig ger con di -
tions are set to 1 and 2. This guar an tees the trig ger con di tions are the same,
and there fore the read ings are valid if taken at the same time.
Changes to the trig ger con fig u ra tions can be made us ing these GPIB com -
mands re gard less of the power me ter op er at ing mode, but will not come into
play un til the unit is con fig ured to use trig gers.
ML2400A OM 6-11
