Step 6.

Press the MARKER key and set the M1 marker to

Marker To Peak. The M1

value should be less than 35 dB return loss.

Step 7.

Press SAVE DISPLAY (page 3-15) name the trace, and press ENTER.

3-6

Chapter 3 Getting Started
