Function Hard Keys
MODE Opens the mode selection box (below). Use the Up/Down arrow key to select a
mode. Press the
ENTER key to implement.
NOTE: Available mode selections will vary according to model number and op
-
tions installed.
FREQ/DIST Displays the Frequency or Distance to Fault soft key menus depending on the
measurement mode (see page 2-18).
AMPLITUDE Displays the amplitude soft key menu for the current operating mode (see page
2-20).
MEAS/DISP Displays the measurement and display soft key menus for the current operating
mode (see page 2-21).
Chapter 2 Functions and Operations
2-5
o Measurement Mode
Freq - SWR
Return Loss
Cable Loss - One Port
DTF - SWR
Return Loss
Power Monitor (External Detector)
Power Meter (Internal)
High Accuracy Power Meter
Spectrum Analyzer
Interference Analyzer
T1 Tester
E1 Tester
Transmission Measurement
Channel Scanner
CW Signal Generator
Figure 2-5. Mode Selection Box
