Selecting the Signal Standard and Channel
Step 1. Press the
Signal Standard soft key and select the appropriate signal standard for
the measurement.
Step 2. Press the
Select Channel soft key and select the appropriate channel for the
measurement.
Selecting the Amplitude
Step 1.
Press the AMPLITUDE key.
Step 2. Press the
Units soft key and select the desired units from the soft keys presented
(Volts or Watts in Linear, dBm, dBV, dBmV, or dBmV in Log). Press the
Back
soft key to return to the Amplitude menu.
Step 3. Press the
Ref Level soft key and use the Up/Down arrow key or directly enter
the desired reference level from the keypad. Press ENTER to set the amplitude
level.
Step 4. Press the
Scale soft key and use the Up/Down arrow key or directly enter the
desired scale from the keypad. Press ENTER to set the scale. Note that the
Scale soft key is not active when Units is set to Linear.
NOTE: Press the Atten/Preamp soft key and select Auto coupling of the attenu-
ator setting to the reference level to help insure that harmonics and spurs are
not introduced into the measurements.
Selecting Bandwidth Parameters
Both resolution bandwidth (RBW) and video bandwidth (VBW) can be automatically or
manually coupled. Auto coupling of the RBW links the RBW to the span. That is, the wider
the span, the wider the RBW. Auto coupling is indicated on the display as
RBW XXX.
When the RBW is manually coupled, it can be adjusted independently of the span. Manual
RBW coupling is indicated on the status window as
RBW* XXX.
Auto coupling of the VBW links the VBW to the RBW. That is, the wider the RBW, the
wider the VBW. Auto coupling is indicated on the display as
VBW=Auto. When the VBW
is manually coupled, it can be adjusted independently of the RBW. Manual VBW coupling
is indicated on the display as
VBW* XXX.
Step 1.
Press the MEAS/DISP key and the
Bandwidth soft key to display the bandwidth
menu.
Step 2. Press RBW Auto for automatic resolution bandwidth selection, or press RBW
Manual
and use the Up/Down arrow key to select the resolution bandwidth.
Press ENTER to set the resolution bandwidth.
Step 3. Press
VBW Auto for automatic video bandwidth selection, or press VBW Manual
and use the Up/Down arrow key to select the video bandwidth. Press ENTER to
set the video bandwidth. Press the
Back soft key to return to the bandwidth
menu.
3-12
Chapter 3 Getting Started
