1-5
Chapter 1 General Information
Part Number Description
15NDF50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to 7/16 DIN (f) 6 GHz
15ND50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to 7/16 DIN (m) 6 GHz
2000-1030 Portable Antenna SMA (m), 50W, 1.71 to 1.88 GHz
2000-1031 Portable Antenna SMA (m), 50W, 1.85 to 1.99 GHz
2000-1032 Portable Antenna SMA (m), 50W, 2.4 to 2.5 GHz
2000-1035 Portable Antenna SMA (m), 50W, 896 to 941 MHz
2000-1200 Portable Antenna SMA (m), 50W, 806 to 866 MHz
2000-1361 Portable Antenna SMA(m), 50W, 5725-5825 MHz
2000-1410 Magnet Mount GPS Antenna with 15 ft. cable
61532 Antenna Kit, consisting of one each:
2000-1030, 2000-1031, 2000-1032,
2000-1035, 2000-1200, and 2000-1361
2000-1411 Portable YAGI Antenna, N(f), 822-900 MHz, 10 dBd
2000-1412 Portable YAGI Antenna, N(f), 885-975 MHz, 10 dBd
2000-1413 Portable YAGI Antenna, N(f), 1.71-1.88 GHz, 10 dBd
2000-1414 Portable YAGI Antenna, N(f), 1.85-1.99 GHz, 9.3 dBd
2000-1415 Portable YAGI Antenna, N(f), 2.4-2.5 GHz, 12 dBd
2000-1416 Portable YAGI Antenna, N(f), 1.92-2.23 GHz, 12 dBd
806-16 Bantam Plug to Bantam Plug
806-116 Bantam Plug to BNC
806-117 Bantam “Y” Plug to RJ48
1030-86 Band Pass Filter, 806-869 MHz, 1.7 dB loss, N(m) to SMA(f), 50W
1030-87 Band Pass Filter, 902-960 MHz, 1.7 dB loss, N(m) to SMA(f), 50W
1030-88 Band Pass Filter, 1.85-1.99 GHz, 1.8 dB loss, N(m) to SMA(f), 50W
1030-89 Band Pass Filter, 2.4-2.5 GHz, 1.4 dB loss, N(m) to SMA(f), 50W
PSN50 High Accuracy Power Sensor, 50 MHz to 6 GHz
3-1010-122 Attenuator, 20dB, 5 Watt, DC to 12.4 GHz, N(m)-N(f)
3-1010-123 Attenuator, 30 dB, 50 Watt, DC to 8.5 GHz, N(m)-N(f)
3-1010-124 Attenuator (Uni-directional), 40 dB, 100 Watt, DC to 8.5 GHz, N(m)-N(f)
42N50-20 20 dB, 5W, DC to 18 GHz, N(m)-N(f)
42N50A-30 30 dB, 50W, DC to 18 GHz, N(m)-N(f)
1010-121 40 dB, 100W, DC to 18 GHz, N(m)-N(f)
