NOTE: The Site Master retains the current GPS location information until the

unit is turned off. This feature allows measurement traces to be saved with the

retained GPS location information even when the GPS is inactive or the instru

ment is indoors.

12-2

Chapter 12 GPS Feature

Figure 12-1. GPS Location Display

Figure 12-2. GPS Quality Display
