A-2
Appendix A Reference Data
Manufacturer Cable Type
Relative
Propagation
Velocity (Vf)
Nominal
Attenuation
dB/m @
1000 MHz
Nominal
Attenuation
dB/m @
2000 MHz
Nominal
Attenuation
dB/m @
2500 MHz
Belden RG8, 8A 0.659 0.262 N/A N/A
Belden RG9, 9A 0.659 0.289 N/A N/A
Belden RG17, 17A 0.659 0.18 N/A N/A
Belden RG55, 55A, 55B 0.659 0.541 N/A N/A
Belden RG58, 58B 0.659 0.558 N/A N/A
Belden RG58A, 58C 0.659 0.787 N/A N/A
Belden RG142 0.659 0.443 N/A N/A
Belden RG174 0.659 0.984 N/A N/A
Belden RG178B 0.659 1.509 N/A N/A
Belden RG188 0.659 1.017 N/A N/A
Belden RG213 0.659 0.292 N/A N/A
Belden RG214 0.659 0.292 N/A N/A
Belden RG223 0.659 0.535 N/A N/A
Cablewave HCC12-50J 0.915 0.087 0.126 0.137
Cablewave HCC78-50J 0.915 0.041 0.061 0.066
Cablewave HCC158-50J 0.95 0.022 0.031 0.033
Cablewave HCC300-50J 0.96 0.015 N/A N/A
Cablewave HCC312-50J 0.96 0.013 N/A N/A
Cablewave HF 4-1/8” Cu2Y 0.97 0.01 N/A N/A
Cablewave HF 5” Cu2Y 0.96 0.007 N/A N/A
Cablewave HF 6-1/8” Cu2Y 0.97 0.006 N/A N/A
Cablewave FLC 38-50J 0.88 0.115 0.169 0.19
Cablewave FLC 12-50J 0.88 0.072 0.11 0.134
Cablewave FLC 78-50J 0.88 0.041 0.061 0.072
Cablewave FLC 114-50J 0.88 0.033 0.05 0.059
Cablewave FLC158-50J 0.88 0.025 0.038 0.042
Comscope CR50 540 PE 0.88 0.069 0.103 0.116
Comscope CR50 1070PE 0.88 0.037 0.055 0.064
Comscope CR50 1873PE 0.88 0.022 0.0344 0.04
Eupen EC4-50 1/2 0.88 0.074 0.109 0.124
Eupen EC4.5-50 5/8 0.88 0.056 0.083 0.094
Eupen EC5-50 7/8 0.88 0.041 0.061 0.069
Eupen EC6-50 1-1/4 0.88 0.03 0.045 0.052
Table A-1. Coaxial Cable Technical Data (2 of 4)
