q
M3 — Selects the M3 marker parameter and opens the Markers second level
menu with M3 highlighted.
q
M4 — Selects the M4 marker parameter and opens the Markers second level
menu with M4 highlighted.
q
All Off — Turns off all markers.
q
More — Press to access additional marker functions:
q
M5 — Selects the M5 marker parameter and opens the M5 marker second
level menu with M5 highlighted.
q
On/Off — Turns the selected marker on or off.
q
Edit — Opens the selected marker parameter for data entry. Enter the
desired marker frequency using the keypad or Up/Down arrow key.
Select the
GHz, MHz, kHz,orHz soft key to accept the marker fre
-
quency input.
q
Marker Freq To Center — Makes the center frequency equal to the
frequency of the selected marker.
q
Peak Between M1 & M2 — Places the selected marker at the fre
-
quency with maximum amplitude value between marker M1 and M2.
q
Valley Between M1 & M2 — Places the selected marker at the fre
-
quency with minimum amplitude value between marker M1 and M2.
q
Back — Returns to the previous menu level.
NOTE: If markers M1 and/or M2 are off, the Peak and Valley functions above
are executed across the entire span.
q
M6 — Selects the M6 marker parameter and opens the M6 marker second
level menu with M6 highlighted.
q
On/Off — Turns the selected marker on or off.
q
Edit — Opens the selected marker parameter for data entry. Enter the
desired marker frequency using the keypad or Up/Down arrow key.
Select the
GHz, MHz, kHz,orHz soft key to accept the marker fre
-
quency input.
q
Marker Freq To Center — Makes the center frequency equal to the
frequency of the selected marker.
q
Peak Between M3 & M4 — Places the selected marker at the fre
-
quency with maximum amplitude value between marker M1 and M2.
q
Valley Between M3 & M4 — Places the selected marker at the fre
-
quency with minimum amplitude value between marker M1 and M2.
q
Back — Returns to the previous menu level.
q
Regular Marker — Measures the signal level at the point of the marker in
the unit type selected in the Amplitude - Units menu. When the regular
marker option is selected, all markers are regular markers.
q
Noise Marker — Measures noise level normalized toa1Hzbandwidth.
The unit of measure is dBm/Hz only. When Noise Marker is selected, the
detection type is automatically changed to RMS average. When the Noise
Marker option is selected, all markers are noise markers.
q
All Off — Turns off all markers.
q
Back — Returns to the previous menu level.
Chapter 2 Functions and Operations
2-51
