19 | PRINTING SETUP
Encoder and Conveyor
When the speed of conveyor is inconsistent, an encoder can ensure the print
length regardless the speed of conveyor.
Press to setup.
 When the Encoder is OFF, input the conveyor speed. Otherwise, go
through CONVEYOR SPEED TEST to determine the speed.
If the input value and actual conveyor speed are not consistent, various
printing issues might occur. To ensure the best print quality, encoder is
recommended.
 When encoder is ON, the conveyor speed will automatically turn OFF.
1. Press to select ON.
2. Input PULSE/CYCLE and DIAMETER of encoder and U2 calculates the DPI
automatically.
Don’t recommend modify PULSE/CYCLE, and default value is 2500.
ANSER offers optional 400DPI encoder with 1.98” wheel diameter.
Conveyor Speed Test
Press to test the conveyor speed.
 When the Encoder is OFF:
1. Input the length of a box you want to print to.
2. Put a physical box on conveyor.
3. When photocell triggers the physical box, the printer calculates the current
