Aplisens PEM-1000 User Manual

IO.PEM-1000(ENG)
02.A.003 11
Figure 3. The flow meter sensor. Overall dimensions
Mechanical data of the sensor PN16
Dimensions [mm]
Weight
DN
PN
A
B
D1
D2
d
n
kg
10
16
150
or 200
153
90
60
14
4
2.5
15
155
95
65
14
4
2.5
20
160
105
75
14
4
3
25
167
115
85
14
4
3.5
32
180
140
100
18
4
5
40
185
150
110
18
4
6
50
200
191
165
125
18
4
7
65
209
185
145
18
4
8
80
224
200
160
18
8
9.5
100
250
245
220
180
18
8
12
125
276
250
210
18
8
15
150
300
305
285
240
22
8
20
200
350
375
340
295
22
12
36
250
400
430
405
355
26
12
58
300
500
487
460
410
26
12
70
350
542
520
470
26
16
85
400
600
615
580
525
30
16
100
450
657
640
585
30
20
120
500
750
715
650
33
20
160
600
870
840
770
36
20
190
700
700
927
910
840
36
24
260
800
800
1050
1025
950
39
24
350
900
900
1145
1125
1050
39
28
450
1000
1000
1285
1255
1170
42
28
550
Table 1. Mechanical data of the sensor – PN 16
