Aplisens PEM-1000 User Manual

IO.PEM-1000(ENG)
02.A.003 33
10.5.2. Table of volumetric flows calculated for the characteristic flow
velocities of the medium for the versions with flanges according to
DIN.
Volumetric flow is calculated based on measured linear velocity of the flow and geometry of
cross-section of the flowmeter. The table presents values of the volumetric flows for the given
DN for characteristic linear velocities of the flow.
DN
Flow velocity V [m/s]
0.300
1.000
2.000
3.000
4.000
5.000
6.000
10
0.085
0.283
0.565
0.848
1.131
1.414
1.696
15
0.191
0.636
1.272
1.909
2.545
3.181
3.817
20
0.339
1.131
2.262
3.393
4.524
5.655
6.786
25
0.530
1.767
3.534
5.301
7.069
8.836
10.603
32
0.869
2.895
5.791
8.686
11.581
14.476
17.372
40
1.357
4.524
9.048
13.572
18.096
22.619
27.143
50
2.121
7.069
14.137
21.206
28.274
35.343
42.411
65
3.584
11.946
23.892
35.838
47.784
59.729
71.675
80
5.429
18.096
36.191
54.287
72.382
90.478
108.573
Flow
100
8.482
28.274
56.549
84.823
113.097
141.372
169.646
125
13.254
44.179
88.357
132.536
176.714
220.893
265.072
[m3/h]
150
19.085
63.617
127.234
190.852
254.469
318.086
381.703
200
33.929
113.097
226.194
339.292
452.389
565.486
678.583
250
53.014
176.714
353.429
530.143
706.858
883.572
1060.287
300
76.341
254.469
508.938
763.406
1017.875
1272.344
1526.813
350
103.908
346.360
692.721
1039.081
1385.441
1731.801
2078.162
400
135.717
452.389
904.778
1357.167
1809.556
2261.945
2714.334
500
212.057
706.858
1413.716
2120.573
2827.431
3534.289
4241.147
600
305.363
1017.875
2035.750
3053.625
4071.501
5089.376
6107.251
800
542.867
1809.556
3619.112
5428.668
7238.223
9047.779
10857.335
1000
848.229
2827.431
5654.862
8482.293
11309.724
14137.155
16964.586
Table 5. Volumetric flow as a function of linear velocity of the medium
