Aplisens PEM-1000 User Manual

IO.PEM-1000(ENG)
02.A.003 31
10.4. Reference conditions
Flow
0.3 - 12m/s
Measured medium
Water 10-30ºC
Conductivity
> 300µS/cm
Supply variability
Un ± 2% (Un – supply voltage)
Ambient temperature
18 - 25 ºC, constant humidity
Stabilization time after
switching on the power
supply
Minimum 20 min.
Straight sections of flow
10 diameters upstream the sensor, 3 diameters
downstream the sensor
Measuring sensor
Centrally located, earthed in accordance with
the fig. 15.
10.5. Metrological parameters
10.5.1. Standard measuring ranges
 PEM-1000 flowmeters are available in the size ranges of flange connections
specified by the DIN standard within the range DN10 ÷ DN1000 or optionally can
be executed in the size range of flange connections in accordance to the ANSI,
BS standard.
 Standard flow values Qmax for the individual versions of the flowmeters with
flange connections in accordance with DIN in the range DN10 ÷ DN1000 are
presented in the table below. It is possible to set the other Qmax flow values for
the individual versions of the flowmeters greater than twice the standard value of
measuring range.
