Aplisens PEM-1000 User Manual

IO.PEM-1000(ENG)
02.A.003 29
10.3. Technical parameters
10.3.1. Technical specification of the sensor
Nominal diameters
DN 101000
Connecting cables to
the converter
Double shielded conductor e.g.
Paar Tronic CY-CY 2x2x0.25mm2 lub 2x2x0.34mm2 (Helukabel)
Unitronic CY PIDY 2x2x0.25mm2 or 2x2x0.34mm2 (Lapp Kabel)
or equivalent.
Length of cable:
0.5m - ALW version
8m or 12m,24m,32m,40m,48m - NW version
Measuring principle
Electromagnetic
Supply ofexciting coil of
the sensor
From converter
Insulation class of
exciting coil
Class E
Field connections
Flanges DIN (ANSI, BS) / hygienic acc. to DIN 11851
Maximum pressure
Standard 1.6 MPa (option 2.5/4.0 MPa)
operation with negative pressure is forbidden
Ingress protection
Standard IP 67, option IP 68 acc. to EN 60529, NEMA 5
(NEMA 6)
Insulation lining
Hard, soft rubber DN20DN1000
Teflon (PTFE) DN10DN500
Range of temperatures
for insulating liners
Rubber (soft), hard -590C, Version PEM-1000NW
Rubber (soft), hard 60C, Version PEM-1000ALW
Teflon -25130C, Version PEM-1000NW
Teflon 060C, Version PEM-1000ALW
Ambient temperature
ranges
-2060C
Electrodes
Steel 1.4571 (316Ti) 1.4404(316L), Hastelloy, Tantalum,
Titanium, Platinum
Outer enclosure and
flanges
Carbon steel, steel 1.4301 (304), steel 1.4541 (321)
Sensor pipe
Steel 1.4541 (321)
Protection coating
Multi-compound Acrymetal varnish
Accessories
Stainless steel earthing rings for plastic pipes for versions
DN10..40
Optional versions of the
sensor
Stainless steel, versions with hygienic grade connectors
Dimensions and weight
According to the table 1, 2, 3.
