02.A.003 37
10.6.1. Electromagnetic compatibility, immunity
Assessment acc. to PN-EN 61326-1, 2 for industrial applications:
Electrostatic discharges (ESD):
PN-EN 61000-4-2
Level S3; Contact ±6kV; Air ±8kV; Criterion B;
Conducted interferences induced by fields with radio frequency:
PN-EN 61000-4-6
0,15…80MHz, 10V; Criterion A;
Electromagnetic fields (radiated interferences):
PN-EN 61000-4-3
80…2000MHz - 10V/m; …2700MHz - 1V/m; Criterion A;
Fast electrical transient conditions (Burst):
PN-EN 61000-4-4
± 2kV supply lines - enclosure; ± 1kV signal lines - enclosure; Criterion B (A);
Surges:
PN-EN 61000-4-5
± 0,5kV (±1kV) signal lines - enclosure ± 1kV (±2kV) supply lines - enclosure; Criterion B;
10.6.2. Electromagnetic compatibility, emissions
Measurements acc. to CISPR 16-1, CISPR 16-2, class B;
Distance of antenna 3m, quasi-peak measurements:
Radiation:
0,15…30MHz; 80-52dBµV/m;
30…2000MHz; <54dBµV/m;
Induction:
0.01…0.15MHz; 96-50dBµV/m;
0.15…0.35MHz; 60-50dBµV/m;
0.35…30MHz; <50dBµV/m;
10.6.3. Mechanical resistance
Impacts:
PN-EN 60068-2-27, 31
50g/11ms
Sinusoidal vibrations:
PN-EN 60068-2-6, test Fc;
To 1.6mm; 2…25Hz;
To 4g for 25…100Hz;
10.6.4. Insulation resistance
>100MΩ @110V DC
10.6.5. Insulation resistance
1330 V AC (1880 V DC), 5 s – rising, 5s - test
10.6.6. Ingress protection of the enclosure
acc. to PN-EN 60529:2003
Sensor - IP 67
Converter – IP 66 or IP 67.
