25
// 4. CONTROLS
4.1 Handbrake lever (rear)
4.2 Handbrake lever (front)
4.3 Throttle grip
4.4 Kill switch
The Handbrake lever (rear) 1 is located to the left of the
handlebar.
Handbrake lever (front) 1 is located on the right handle-
bar. The front brake is operated by the handbrake handle.
The throttle grip 1 is fitted on the right side of the
handlebar.
Kill switch 1 is fitted on the left side of the handlebar.
Possible states:
// Kill switch in basic position
In this position, the ignition circuit is closed and the
engine can be started.
// Kill switch pressed
In this position, the ignition circuit is interrupted, a
running engine stops, and a non-running engine will not
start.
1
1
1
1
