79
17.5 Chassis
Frame Steel central tubular frame
Fork VOLT SUSPENSION V-ONE 25
Front suspension travel 110mm
Shock absorber VOLT SUSPENSION V-ONE 190mm
Rear suspension travel 20mm
Brake system Disc brakes, floating brake calipers
Diameter of brake discs
Front 170 mm
Rear 170 mm
Brake discs - wear limit 2.2 mm (0.087 in)
Tire air pressure o road 1,0 bar (15 psi)
Secondary ratio
Chain SF420
Rear sprockets available 37,39,41,43,45
Steering head angle 23°
Wheelbase 855±10 mm
Ground clearance, unloaded 180mm
Seat height, unloaded 560mm
Weight without fuel, approx. 43kg
Maximum permissible 50 kg
17.6 Tires
Front 2.5-10
Rear 2.5-10
