71
Preparatory work
• Park the motorcycle on a level surface.
Main work
• Place a suitable container under the engine.
• Remove oil drain plug 1 with the magnet and seal ring.
• Mount and tighten oil drain plug 1 with the magnet.
Guideline
Oil drain plug with magnet M8 20 Nm (14,8 lbf ft)
1
• Stand the motorcycle upright.
• Remove filler plug 2 with the O-ring from the clutch cover
and fill up with engine oil..
Motor oil 0,7L (SAE 10W40)
Too little engine oil or poor-quality engine oil results in premature wear of the engine.
Install and tighten the oil filler plug with O-ring.
2
• Start the engine and check that it is oil-tight. Finishing work
• Check the engine oil level. ( .70)
Intoxication danger
Exhaust gases are toxic and inhaling them may result in unconsciousness and
death.
Always make sure there is sucient ventilation when running the engine.
Use an eective exhaust extraction system when starting or running the engine
in an enclosed space.
