Basics Backside Cache - 47
Backside Cache
Backside cache is a significant architectural design change
from earlier PowerPC processors. The main advantage of the
backside cache architecture is the speed of the dedicated
CPU-to-L2 cache interface. Using the dedicated bus allows
the CPU to access the fast L2 cache storage through a high
speed bus without addressing the slower system bus or
competing with other devices attached to the system bus.
In comparison, a “far-side” cache running on the system bus
would limit that SRAM interface to 50MHz.
The PowerPC G3 microprocessor interfaces with SRAM
storage via a dedicated bus running at various multiples of
the core PLL CPU speed. With high speed L2 SRAM and a
dedicated L2 bus, the CPU can access stored information up
to the speed of the processor clock. L2 access is
determined by the clock ratio setting. For example, with a
