Troubleshooting Video Flow/ - 20
Video Flow
Video signals begin on the logic board at connector J16 and travel
to connector J8 on the A/V interconnect board. The video signals
then travel out from connector J6 (on the opposite side of the A/V
interconnect board) and continue on via the internal RGB cable to
P301 on the analog/video board. From there, the signals are
transmitted to the CRT where they are displayed on the screen.
Click on the icon below to see an animation of how the video signal
travels through the iMac.
