Result Queries
These commands are used to query results data from the instrument. The query command will read the
parameter that is stored for each Sequence in the List Mode operation. For other output modes, use
MEASURE Subsystem commands to query live data while the unit is outputting.
7.4.5 Result Subsystem
BASE KEYWORD DESCRIPTION VALUE
RESult
:SEQuence <value>
:SEQuence?
Select Sequence Number
:STATe? Query State
OFF, ON, TRIG TO TEST,
Ramp Up , Ramp Down ,
OVP_PEAK , OCP_PEAK ,
OPP_PEAK , OVP , OCP ,
OPP , FAN_FAIL , DA_OTP
, MCU_FAIL , DD_OVP
, DD_LVP , DD_OCP ,
CALIBRATION_ERROR ,
INT_TEST_FAIL , DD_FAIL ,
RCP_PEAK , RCP , UTPUT_
SHORT , SET_FAIL , AC_OVP
, AC_LVP, PFC_OVP, PFC_LVP,
PFC_OCP, PFC_OTP, DD_
OTP, VSENSE_INT_OVP,
VSENSE_INT_LVP, VSENSE_
EXT_OVP, VSENSE_EXT_LVP,
A-Hi, A-Lo, P-Hi, P-Lo, VA-Hi,
VA-Lo, Q-Hi, PF-Hi, PF-Lo,
CF-Hi, CF-Lo, AP-Hi, AP-Lo
:TOTal? Query Total Results Available
:ALL? Query Meter Data
Voltage, Vac voltage, Vdc
voltage, Current, AC current,
DC current, Frequency,
Power, Pfactor, APEAK,
Reactive, Crestfactor,
Apparent
:VOLTage:AC? Query AC Voltage 0.0 – 310,0 VAC
:VOLTage:DC? Query DC Voltage 0.0 – 420.0 VDC
:VOLTage:STARt? Query Start Voltage -
:VOLTage:END? Query End Voltage -
:FREQuency? Query Frequency 5.0 – 1200 Hz
:CURRent:AC? Query AC Current *See Specifications
:CURRent:DC? Query DC Current *See Specifications
:POWer? Query Power *See Specifications
:PFACtor? Query PFACtor 0.000 – 1,000
:APEAK? Query Amps Peak 0.0 – 50.0 A
:REACtive? Query Reactive Power *See Specifications
