Revision Date – 22/12/2014 page 60
9.16 Rubber feet – Remove and Refit
Remove 1 M6 bolt from the centre of the rubber
foot using a 5 mm hex key.
Remove the rubber foot from the recess in the
base of the fridge.
Install the new rubber foot into the recess in the
base of the fridge.
Fasten the rubber foot to the body of the fridge
using the original M6 bolt.
NOTE: When tightening the M6 bolt, do not
exceed an assembly torque of 3.5 Nm
(2.5 ftlb).
