Revision Date – 22/12/2014 page 8
The following items are not illustrated in section 4.2.
DC Plug adaptor - Red collar
Fuse DC ceramic 12/24V T8A 32V (see section 12.)
Fuse DC Glass 12/24V 15Amp type 3AGA
Cover Socket – Rear Panel for wireless transmitter
Lead PCB - Main PCB to wireless transmitter
Mount Bracket –Fridge Remote Display
DC Lead - Fridge Remote Display
4.2 Spare parts exploded drawing
The items in the following exploded diagram correspond with the items in the table in section 4.1.
