Revision Date – 22/12/2014 page 61
9.17 Compressor mounting feet – Replace
To Remove compressor mounting feet
Disconnect all power leads from the back of the
fridge.
Remove the rear cover (refer to section 9.2).
Remove the retaining clip by sliding it sideways
off the pin.
HINT: A flat blade screwdriver may be useful
to help remove the retaining clip.
HINT: Press down on the steel compressor
base to compress the rubber mounting
bush.
Withdraw the pin, washer and rubber bush.
