9.22 Thermistor – Replace
Fridge with non-serviceable thermistors
The thermistor is non-servicable on 47L fridges with serial numbers up to and including those listed in
the table below. Please contact ARB for service advice for these fridges.
For fridges with serviceable thermistors
All 35L, 60L and 78L fridges have serviceable thermistors. All 47L fridges with serial numbers higher
than those listed in the table above also have serviceable thermistors. Please follow the procedure below
to replace a serviceable thermistor.
Disconnect all power leads from the back of the
fridge.
Remove the rear cover (refer to section 9.2).
Remove and retain the screw, “P”-clip and sealing
compound that retain the thermistor wire.
This screw is located in the bottom right hand
corner of the fridge cabinet as shown.
To Next Page
