Fitting instructions# 3789528
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
18. If vehicle is fitted with radar, refer to fitting
instructions supplied with adaptive cruise
control kit (Part No. 3540200 - purchased
separately) for removal and relocation.
If not, proceed to step 19.
NOTE: Radars are initialised to each vehicle
and cannot be used on other vehicles.
19. Use a screw driver to push the 2 x plastic clips
inward from the front cross beam. Do not
remove the clips as they will be used later.
20. Remove the factory under panel and place in
a safe place. Do not completely remove the
rear bolts. Leave loose.
21. Remove the front cross beam and discard.
