20
Select Bum-back time
You can also choose to use the default Settings
Function with separated Part Select
Select MIG
Close SYN
/
Turn the knob to find the required voltage
Turn the knob to find the required IPM
Select 2T / 4T / Spot
If you select spot mode
Please adjust the spot time
Select inductance level
You can also choose to use the default Settings /
Select Bum-back time
You can also choose to use the default Settings
NOTICE:
•
Always weld clean, dry and well-prepared
material.
• Hold gun at a 45° angle to the workpiece with
nozzle about 1/2” from the surface.
•
Move the gun smoothly and steadily as you
weld.
• On thin gauge material, move quickly and only
weld 1/4” stitch-welds at a time to avoid
melt-through.
•
Avoid welding in very drafty areas. A weak,
pitted and porous weld will result due to drafts
blowing away the
Figure 26
